Product Overview
Depending on screen size and the distance between the wall plates, the articulating arms offer up to 40° of swivel in either direction. Further improve line-of-sight and reduce glare by tilting your TV 15° forward or 3° backward. The PDC650 also includes cable management clips and wall plate covers to ensure a professional looking setup.
Secure Corner Mounting
Featuring two independent wall plates, the PDC650 allows for TVs weighing up to 125 pounds to be safely mounted to any corner, column or pillar.
Pan and Swivel
Swivel the articulating arms up to 40° in either direction to ensure your TV is properly positioned. Note that the range of movement will depend on the size of your TV and the location of the wall plates.
Angled Viewing
In order to reduce glare and improve line-of-sight with your TV, the VESA-compliant TV brackets can be tilted 15° forward and 3° backward.
Tidy Setup
Cable management clips are provided to conveniently route your cables, while plastic wall plate covers hide any sign of installation.
Everything You Need
The PDC650 comes with a convenient bolt box containing all the lag bolts, anchors, washers and spacers you’ll need to safely mount your TV.
Features and Specifications
Fits most fl at panel TVs from 37” to 70”
Supports TVs up to 125 lb (57 kg)
Accommodates VESA sizes from 100x100 to 600x400
Suitable for inner and outer corners, as well as pillars and columns
Accessible tilt mechanism provides a +15° to -3° viewing angle
40° of swivel in either direction, depending on screen size and location of the wall plates
Sits 2” (5 cm) from the wall
Extends up to 21.2” (53.8 cm) from the wall
Adjustable horizontal leveling
Integrated cable management
Solid steel construction with durable powder coated finish
Includes manual and all mounting hardware for wood stud and concrete installation
Five year manufacturer’s warranty
Shipping box weight: 27.1 lb (12.3 kg)
Shipping Box Dimensions: 29.6’’ x 14.3’’ x 3.9’’ (75.3 x 36.3 x 10 cm)
Product Weight: 23.3 lb (10.6 kg)
